CP1 PVC FABRIC -CP01

Name: CP1 PVC FABRIC -CP01 - Shade & Canvas
Availability: InStock

Add to Wishlist

Compare

19 people are viewing this product right now

CP1 PVC Fabric is a heavy-duty, architectural-grade coated fabric designed for demanding outdoor applications such as tents, canopies, shade structures, car parking shades, and exhibition setups. Made with a high-tenacity polyester core and coated with premium PVC on both sides, it offers excellent tensile strength, tear resistance, flame retardancy, UV protection, mildew resistance, and long-lasting weather durability. Its smooth PVDF/acrylic lacquer finish helps resist dirt buildup and makes cleaning easier, making it a reliable fabric solution for strong, waterproof, and low-maintenance outdoor structures.

Estimated delivery:5 days

Shipping calculated at checkout.

SKU: N/A Tags: Building Materials, Ready Made Categories: PVC

Custom-made Options available

Tell us what you need and we will prepare a custom quote

Have any Questions?

Feel free to Get in touch

Guaranteed safe checkout

Your Payment is 100% Secure

Product details

CP1 Grade-1 PVC Coated Fabric is made from a high-tenacity, low-wick polyester base fabric and coated on both sides with premium PVC resin. It is designed to deliver strong tensile performance, tear resistance, flame retardancy, and reliable protection against harsh outdoor conditions.

The fabric features a dual-sided PVDF/high-gloss acrylic lacquer finish, which improves UV resistance, helps prevent dirt buildup, and makes cleaning easier. Its strong weldability also makes it suitable for hot-air, wedge, and high-frequency welding applications.

Key Features

Heavy-Duty Strength

Made with a 1000D × 1000D woven polyester core for strong resistance against tension, wind loads, and outdoor wear.

UV & Weather Resistant

Designed to withstand sun exposure, rain, and changing outdoor conditions.

Waterproof & Weldable

Suitable for creating strong waterproof seams through hot-air, wedge, or high-frequency welding.

Flame Retardant

Listed as Class B1 / M2 / NFPA 701 compliant for safer use in tents and outdoor structures.

Easy Maintenance

Smooth lacquer finish helps reduce dirt buildup and allows easy cleaning with mild detergent and water.

Suitable Applications

Event tents
Luxury marquees
Canopies
Car parking shades
Exhibition structures
Shade sails
Outdoor fabric covers

Available Variations

Variation	Roll Width	Roll Length	Weight	Finish
CP1 PVC Fabric	1.50m	50m	650 gsm ± 20 gsm	PVDF / High-gloss acrylic lacquer
CP1 PVC Fabric	2.50m	50m	650 gsm ± 20 gsm	PVDF / High-gloss acrylic lacquer
CP1 PVC Fabric	3.00m	50m	650 gsm ± 20 gsm	PVDF / High-gloss acrylic lacquer

Technical Specifications

Property	Specification
Fabric Type	PVC coated architectural fabric
Base Fabric	High-tenacity low-wick polyester
Yarn Count	1000D × 1000D
Density	18 × 18 per inch
Total Weight	650 gsm ± 20 gsm
Tensile Strength	2500 N / 2300 N per 50mm
Tear Strength	250 N / 230 N
Coating Adhesion	90 N / 50mm
Temperature Resistance	-30°C to +70°C
Surface Finish	Dual-sided PVDF / high-gloss acrylic lacquer
Mold Resistance	Grade 0, complete inhibition

Care & Handling

Store rolls horizontally in a cool, dry place away from direct sunlight. Clean using mild detergent, soft cloths, or low-pressure water spray. Avoid strong solvents, acetone, stiff brushes, and high-acid chemicals.
